The LPX500 marks a new step in the LeaderPhabrix Test & Measurement lineup. It combines SDI and IP analysis in a single, unified platform designed to keep up with ST 2110 infrastructures.
At the core of the system are four independent analyzers, allowing simultaneous display of:
- 4 x 12G-SDI inputs
- 2 x 100GbE IP inputs, in parallel
The 2 × 100G capability makes it possible to handle multiple UHD streams, monitor several ST 2110 essences, manage redundancy paths, validate PTP, and perform high-bandwidth network diagnostics. The LPX500 provides direct visibility of both links, a key advantage when validating and monitoring modern IP infrastructures.
A genuinely useful display extension
The LPX500 can be equipped with a second touchscreen display that mirrors the interface of the main unit.
It connects via USB-C, functions as an autonomous screen, and can display any view through the DisplayPort or SDI Mon outputs.
The two integrated VNC clients significantly improve the responsiveness of remote control, ideal for supervision or supporting teams across multiple sites.
A clear interface, designed for complex workflows
The interface follows the familiar PHABRIX “app-style” approach, allowing optimal use of screen space and avoiding cluttered layouts:
- gesture-based navigation (swipe, drag, hold),
- layout-based organization to group instruments,
- extended screen space for viewing multiple measurements at once.
The result is a clear, readable view of SDI and IP signals, even when working within dense, high-traffic systems.
