5 Reasons Sx TAG IP is ideal for ST 2110 Test & Measurement

2 minutes read
alt=
The Sx TAG by PHABRIX offers incredible versatility in a handheld device! With its SFP, SDI and analog I/O, it is ideal for IP, 3G/HD/SD-SDI, optical SDI, HDMI and Analog test & measurement, plus AES eye analysis. Discover five reasons why the Sx TAG IP is the ideal tool for ST 2110 test & measurement:
.
1. Ideal for checking IP 2110/2022-6/2022-7, 3G/HD/SD-SDI, optical SDI, HDMI and Analog signals
The Sx TAG’S SFP+ cage supports coaxial and optical 3G/HD/SD-SDI, HDMI, and 10G-IP I/O. Coupled to the TAG’s existing SDI, CVBS, AES and balanced audio I/O a vast array of signal generation, analysis and conversion capabilities are provided including encap/decap of ST 2110-20/30/31/40 flows to/from an SDI gateway with ST2059 PTP, AMWA NMOS IS-04/IS-05/IS-08, as well as ST 2022-6 and even the ability to generate an analog reference locked to ST 2059 PTP or 2022-6.
PHABRIX_Sx_1.-contrôler-les-signaux-IP_TEVIOS
2. Extensive Video Analysis Toolset
With simultaneous signal generation and analysis, its built-in core toolset includes a multi-format waveform, vectorscope and video display, plus data view and VANC/ANC inspector. Over 350 formats are supported for compliance monitoring. Signal generation offers 32 test patterns, including pathological.
PHABRIX_Sx_2-outils-d'analyse-vidéo_TEVIOS
3. AV Delay Generation and Analysis
AV Delay Generation and Analysis offers an end-to-end solution for the measurement of Audio to Video differential delay through a broadcast system. The tool provides a realtime update of the differential delay between the video content and the selected audio channel pair to measure the propagation (latency) or pipeline delay.
PHABRIX_Sx_3-Génération-analyse-des-retards-AV_TEVIOS
4. Multi-channel audio analysis
The Sx TAG features support for 16-channel audio metering and bitstream generation and analysis of Dolby E, Dolby Digital and Dolby Digital Plus. Embed a single external 48kHz synchronous AES stream into the generated video stream, as well as extract embedded audio and export it via the AES output.
PHABRIX_Sx_4-Analyse-audio-multicanal _TEVIOS
5. Ultra portable, rugged design
The Sx TAG offers great mobility with a lightweight, rugged aluminium case with integral, high quality screen for instrument display and video monitoring. The generator/ analyzer operates via rechargeable lithium battery for up 2 hours, and can also be powered by the mains to offer flexible operation around facilities.
PHABRIX_Sx_5-Ultraportable-conception-robuste _TEVIOS
Contact us for more information about the Sx TAG IP by PHABRIX!
